Balance 30 PRO

Unbreakable Branch Connectivity

The Balance 30 Pro comes equipped with two Ethernet WAN and one cellular WAN for automatic failover, making it an ideal choice for branch offices that absolutely must stay connected.

400Mbps Dual-WAN Router with LTE-A Balance 30 PRO #2
400Mbps Dual-WAN Router with LTE-A Balance 30 PRO #2

There’s a Perfect Balance for Every Situation

Peplink ‘s line of products includes features that make your enterprise deployment easier and increase your network reliability and security in several ways. Boost network data rates, reliability, and flexibility while slashing connectivity costs with Peplink SD-WAN technology designed for multi-WAN link load balancing. Use Load Balancing and SpeedFusion bandwidth bonding to deliver superfast VoIP, video streaming, and data using an SD-WAN enabled network.

  • Branch/Small Office
  • Small Business
  • Mid-Size Business
  • Large Enterprise/Campus
  • Cloud/VM

Compatible With:

  • 2.5Gbps Quad Cellular Gigabit LTE Mobile PowerhouseMAX HD4 MBX #10
  • 2.5Gbps Quad Cellular Gigabit LTE Mobile PowerhouseMAX HD4 MBX #6
  • 2.5Gbps Quad Cellular Gigabit LTE Mobile PowerhouseMAX HD4 MBX #3
  • 2.5Gbps Quad Cellular Gigabit LTE Mobile PowerhouseMAX HD4 MBX #5
  • 2.5Gbps Quad Cellular Gigabit LTE Mobile PowerhouseMAX HD4 MBX #8
  • 2.5Gbps Quad Cellular Gigabit LTE Mobile PowerhouseMAX HD4 MBX #4
  • 2.5Gbps Quad Cellular Gigabit LTE Mobile PowerhouseMAX HD4 MBX #9

Compatible with all major carriers. Certified on Verizon.

Use Cases

Retail
Hospitality
Branch Networking

Compatible With:

  • 2.5Gbps Quad Cellular Gigabit LTE Mobile PowerhouseMAX HD4 MBX #10
  • 2.5Gbps Quad Cellular Gigabit LTE Mobile PowerhouseMAX HD4 MBX #6
  • 2.5Gbps Quad Cellular Gigabit LTE Mobile PowerhouseMAX HD4 MBX #3
  • 2.5Gbps Quad Cellular Gigabit LTE Mobile PowerhouseMAX HD4 MBX #5
  • 2.5Gbps Quad Cellular Gigabit LTE Mobile PowerhouseMAX HD4 MBX #8
  • 2.5Gbps Quad Cellular Gigabit LTE Mobile PowerhouseMAX HD4 MBX #4
  • 2.5Gbps Quad Cellular Gigabit LTE Mobile PowerhouseMAX HD4 MBX #9

Compatible with all major carriers. Certified on Verizon.

Retail Connectivity Solution

The Balance 30 Pro can handle all your networking needs. With the PoE activation kit, its four PoE LAN ports can connect and power your payment terminal, IP phones, Wi-Fi hotspots. The Balance 30 Pro has one cellular and two Ethernet connections, ensuring that your network and business will keep running no matter what. With Peplink PrimeCare Advance, you can enjoy turn the Balance 30 Pro into a source of revenue and customer data. Use the Ad Delivery service to deliver advertisements and surverys to your customers before they connect to your Wi-Fi.

400Mbps Dual-WAN Router with LTE-A Balance 30 PRO #4

Branch Site Setup

In this video Peter from West Networks demonstrates how to use the Balance 30 Pro to deploy branch office connectivity in under 5 minutes.

SD-WAN With Dual Wired Ports and LTE

The Balance 30 Pro supports two wired connections and one LTE with SD-WAN capabilities for traffic steering, load sharing and failover, powering your critical business continuity.

Redundant SIM Slots

Redundant SIM slots with automatic switching for reliable network. You can set the Balance 30 Pro to automatically switch SIM cards when you’re in danger of data overage, or aggregate capacity of multiple SIM data plans.

Add PoE Kit to Enable 4-port PoE Switch

With the PoE activation kit, all LAN ports can support PoE output. That way, you can hook PoE powered devices such as IP Phones and additional Wi-Fi APs. Perfect for Branch Networking.

Speed & Reliability. Brought by SpeedFusion™

SpeedFusion allows users to combine any number of connections together to form a point-to-point link to achieve what others cannot:

Combine the bandwidth of several mobile connections to form an ultra-fast data link. Sustain bandwidth-hungry and latency sensitive tasks without the need for fixed lines.

Hot Failover maintains secure tunnels over all available WAN links to keep the network up and running when a connection drops out. If a WAN link fails, SpeedFusion instantly routes traffic to a working tunnel for uninterrupted VoIP sessions.

SpeedFusion is carrier agnostic and our products are certified with multiple carriers. By combining the coverage network of several mobile carriers, chances of running into a network blindspot or congestion is minimized.

With the help of WAN smoothing network traffic will be assigned to WAN connection with the lowest latency. Use multiple WAN connections to create a single, jitter-free data stream.

400Mbps Dual-WAN Router with LTE-A Balance 30 PRO #6

Built to Last

Capable of years of uptime, the Balance  series easily handles monthly bandwidth that would crush lesser equipment. Every Peplink design is rigorously tested to exceed your expectations for speed, reliability, durability, and ease-of-use. We invest heavily in quality assurance and user experience testing to give you affordable, enterprise-class gear that just works, from the moment you take it out of the box.

InControl 2. Powerful Cloud Management Platform

Balance 30 PRO  is supported by InControl, Peplinks Cloud-Based SD-WAN Network Management Platform, which lets you provision, monitor, and manage your routers. All from a single screen.

InControl makes your network scalable. From any web browser, you could remotely push a wide range of settings to multiple devices in your network

Captive Portal
QoS

400Mbps Dual-WAN Router with LTE-A Balance 30 PRO #7





Customizable Captive Portal With Ad Delivery



Use InControl to customize the captive portal and apply it to any SSID. With InControl’s scalable architecture, you can apply the SSID to multiple devices in your network using device tags. Use the cloud-based Ad Delivery Service (ADS) to monetize your Hotspot.

400Mbps Dual-WAN Router with LTE-A Balance 30 PRO #8





QoS : Determine Traffic Priority



QoS enables you to assign different priority levels to different types of traffic. Minimize latency by giving high priority to VoIP traffic. Control data costs by limiting the speed of bandwidth-intensive applications.

Web Admin Demo

Experience powerful features of Balance Series web admin online demo.

Note: This is for demonstration purposes only and may differ from our latest UI. Functionality also varies amongst models.

Administrator Username and Password: admin / admin
Read-only Username and Password: user / user

#PowerofPeplink

  • Product CodeBPL-031-LTEA
    WAN Interface2x GE
    1x Embedded LTE-A Modem
    1x USB Interface
    LAN Ports4x GE PoE #
    Wi-Fi InterfaceDual-Band 802.11ac/a/b/g/n Access Point
    Embedded 4G LTEYes
    LTE-A ModemDownlink/Uplink Datarate:
    300Mbps/50Mbps
    SIM Card SizeMini-SIM (2FF)
    USB WAN Modem Port [1]1
    Recommended Users [2]1-60
    Stateful Firewall Throughput [3]400Mbps
    802.1q VLANs Supported16
    Port-Based VLANYes
    Load Balancing & FailoverYes
    Load Balancing Algorithms8
    InControl Cloud ManagementYes
    PepVPNYes
    SpeedFusion Hot FailoverYes
    SpeedFusion WAN SmoothingOptional feature ^
    SpeedFusion Bandwidth BondingOptional feature ^
    Number of PepVPN/SpeedFusion Peers [4]2/5 !
    PepVPN Throughput (256-bit AES) [3]55Mbps
    PepVPN Throughput (No Encryption) [3]120Mbps
    IPsec VPN (Network-to-Network) [5]Yes
    Number of IPsec Tunnels2
    Remote User AccessYes
    L2TP VPN ServerYes
    OpenVPN ServerYes
    PPTP VPN ServerYes
    Recommended PPTP/L2TP/OpenVPN Users15
    GRE (Network-to-Network)5
    AP Controller Functionality Yes
    Pepwave AP Series ManagementYes
    Maximum Number of AP Supported30
    Remote AP & Multiple Config Profiles Management [6]no
    Bandwidth Usage MonitorYes
    QoS for VoIP and E-CommerceYes
    User Groups Bandwidth ControlYes
    Web BlockingYes
    Web Filtering BlacklistNo
    Operating Temperature-40° – 149°F | -40° – 65°C
    LACP (802.3ad) NIC BondingNo
    Power Consumption28W
    High AvailabilityYes
    FCC, CE, RoHSYes
    Warranty1-Year Limited Warranty

    [1] For a list of supported modems, please refer to https://archive.peplink.com/modem.
    [2] Recommendation for sizing purposes only. No software restrictions applied.
    [3] Router Throughput and PepVPN/SpeedFusion Throughput is based on Ethernet frame sizes of 1280 or 1518 bytes. Actual performance can vary across different networking environments. Figures apply to the latest hardware revision.
    [4] Number of peer Peplink or Pepwave devices you can connect using SpeedFusion VPN.
    [5] IPsec only supports connection with Cisco, Juniper, Peplink or Pepwave devices.
    [6] Balance 20/30 LTE/One/210/310 comes with AP Controller Standard, which supports up to two configuration profiles with multiple SSIDs, meaning that all APs will share the same configuration, and you can only manage APs on the local physical LAN. Balance 305/380/580/710/1350/2500 comes with AP Controller Pro, which supports multiple configuration profiles with multiple SSIDs, and you can manage remote APs outside the local physical LAN.
    ! 2 PepVPN Peers are enabled by default. Can be increased to 5 Peers using license PVN-LC-05.
    ^ Available as a license add-on.
    # PoE Activation Kit is available separately. Needs at least 48V of input for PoE output.

  • WANSupport for PPPoE, Static IP, DHCP
    WAN Link Health Check
    - PING
    - DNS Lookup
    - HTTP
    Bandwidth Allowance Monitor
    USB 4G/3G Modem Support
    Intelligent Failover
    Support for Dynamic DNS services
    - changeip.com
    - dyndns.org
    - no-ip.org
    - tzo.com
    - DNS-O-Matic
    LANDHCP Server for LAN Clients
    Extended DHCP Option
    DHCP Reservation
    DNS Proxy for LAN Clients
    VLAN on LAN Support
    Load BalancingIntelligent Failover
    Per-Service Load Distribution
    Multiple Algorithms
    - Weighted
    - Enforced
    - Persistence
    - Priority
    - Overflow
    - Least Used
    - Lowest Latency
    Complete VPN SolutionPepVPN
    - Site-to-Site VPN
    - Hot Failover
    - 256-bit AES Encryption
    - Pre-shared Key Authentication
    - Dynamic Routing
    PPTP VPN Server
    - RADIUS, LDAP Authentication
    IPsec VPN (Network-to-Network)
    - X.509 Certificate Support
    Advanced QoS User Groups
    - Bandwidth Reservation
    - Individual Bandwidth Limit
    Application Prioritization
    - By User Groups
    - SIP, HTTPS, VPN QoS
    - Custom Application QoS
    NetworkingNAT and IP Forwarding
    Static Routes
    Port Forwarding
    Many to One, One to One NAT
    NAT Pool
    SIP ALG, H.323 ALG
    UPnP, NAT-PMP
    WINS Server
    BGP, OSPFv2 and RIPv2 Support
    SecurityDoS Prevention
    Stateful Firewall
    Captive PortalSupport for Wired and Wireless LAN Clients
    Support RADIUS Authentication
    Support LDAP Authentication
    Time and Usage Quotas on Open Access Mode
    Built-in Customizable Splash Page
    Power RequirementsDC Jack: 10V – 56V
    CertificationsCE
    FCC
    RoHS
  • Product CodeProduct NameDescription
    PVN-LC-05PepVPN License Key for Velocity and BR1 familyEnables up to 5 PepVPN connections
    • Balance 30 Pro
    • 2x 2dBi 4G LTE Antennas (ACW-813)
    • 4x Wi-Fi Antennas (ACW-341)
    • 4x Wi-Fi Antenna Extender with Magnetic Base (ACW-800)
    • 12V2A Power Supply (ACW-601)
    • 1 Pair of Mounting Brackets (ACW-721)
  • Product CodeCarrierEmbedded Modem 4G Bands 3G Bands
    BPL-031-LTEA-W-TWorldwide14G LTE-A:
    B1, B2, B3, B4, B5, B7, B8 , B12, B13, B20, B25, B26, B29, B30, B41
    WCDMA/HSPA+/DC-HSPA+: B1, B2, B3, B4, B5, B8
    BPL-031-LTEA-P-TEurope/International14G LTE-A:
    B1, B3, B5, B7, B8, B18, B19, B21, B28, B38, B39, B40, B41
    WCDMA/HSPA+/DC-HSPA+: B1, B5, B6, B8, B9, B19
    TD-SCDMA: B39
