Specifications
No differences
Ethernet Port
1x Gigabit Ethernet
Ethernet Port
3x Gigabit Ethernet
Ethernet Port
1x Multigigabit Ethernet
Wi-Fi Standard
Wi-Fi 5
Wi-Fi Standard
Wi-Fi 5
Wi-Fi Standard
Wi-Fi 6
Data Rates
2×2 MU-MIMO
2.4GHz: up to 300Mbps
5GHz: up to 866Mbps
Data Rates
2×2 MIMO
2.4GHz: up to 300Mbps
5GHz: up to 866Mbps
Data Rates
4×4 MU-MIMO
2.4GHz up to 1148Mbps
5GHz: up to 2400Mbps
Recommended Concurrent Users Per Radio
60
Recommended Concurrent Users Per Radio
60
Recommended Concurrent Users Per Radio
256
Multiple SSIDs
16
Multiple SSIDs
16
Multiple SSIDs
16
Wireless Security
Open (No Encryption) 1
OWE
WPA3 – Personal (HW2)
WPA3 – Enterprise (HW2)
WPA2/WPA3 – Personal (HW2)
WPA2 – Personal
WPA2 – Enterprise
WPA/WPA2 – Personal
WPA/WPA2 – Enterprise
WPA2/WPA3 Personal, WPA3 Personal requires AP Firmware 3.6.2 and 3.7.1 or above.WPA3 Enterprise requires AP Firmware 3.9.2 or above.
Wireless Security
Open (No Encryption) 1
OWE
WPA3 – Personal
WPA3 – Enterprise
WPA2/WPA3 – Personal
WPA2 – Personal
WPA2 – Enterprise
WPA/WPA2 – Personal
WPA/WPA2 – Enterprise
WPA2/WPA3 Personal, WPA3 Personal requires AP Firmware 3.6.2 and 3.7.1 or above.WPA3 Enterprise requires AP Firmware 3.9.2 or above.
Wireless Security
Open (No Encryption)
Enhanced Open (OWE)
WPA3 – Personal (AES:CCMP)
WPA3 – Enterprise (AES:CCMP)
WPA2/WPA3 – Personal (AES:CCMP)
WPA2 – Personal (AES:CCMP)
WPA2 – Enterprise (AES:CCMP)
WPA/WPA2 – Personal (TKIP/AES: CCMP)
WPA/WPA2 – Enterprise (TKIP/AES: CCMP)
Transmit Power
2.4GHz: 22dBm
5GHz: 23dBm
Transmit Power
2.4GHz: 20dBm
5GHz: 20dBm
Transmit Power
2.4GHz: 25dBm
5GHz: 25dBm
Antenna
Built-In Omni Antenna
Antenna
2x Dual-Band Omni Antenna
-
Antenna
Built-in Omni Antenna
Antenna Gain
2.2dBi for 2.4GHz
3dBi for 5GHz
Antenna Gain
3dBi for 2.4GHz
3dBi for 5GHz
Antenna Gain
5dBi for 2.4GHz
5dBi for 5GHz
Antenna Connector
N/A
Antenna Connector
2x RP-SMA Connectors
Antenna Connector
N/A
Enclosure
Plenum-rated
Indoor Plastic
Enclosure
Ruggedized Metal
Enclosure
Plenum-rated
Indoor Plastic
Dimensions
3.9 x 3.9 x 0.8 inches
98 x 98 x 19.7 mm
Dimensions
4.8 x 4.2 x 1.4 inches
122.1 x 107 x 35 mm
Dimensions
8.1 x 8.1 x 1.3 inches
205 x 205 x 32 mm
Weight (Pound)
0.33 pounds
Weight (Pound)
0.8 pounds
Weight (Pound)
1.73 pounds
Weight (Kilogram)
150 grams
Weight (Kilogram)
365 grams
Weight (Kilogram)
785 grams
Power Input
AC Adapter: 100V – 240V to 12V2A / 30V1A DC
802.3at PoE+
Power Input
DC Jack: 12V 3
AC Adapter: 100V – 240V to 12V2.5A DC
802.3at PoE+
AC Adapter as an optional feature (ACW-602).PoE Injector is available separately (ACW-107).
Power Consumption
12W (max.)
Power Consumption
13W (max.)
Power Consumption
23W (max.)
Operating Temperature
23° – 113°F
-5° – 45°C
Operating Temperature
-40° – 149°F
-40° – 65°C
Operating Temperature
32° – 104°F
0° – 40°C
Humidity
15% – 95% (non-condensing)
Humidity
15% – 95% (non-condensing)
Humidity
15% – 95% (non-condensing)
Warranty
1-Year Limited Warranty
Warranty
1-Year Limited Warranty
Warranty
1-Year Limited Warranty
