Balance Your Fixed Network with 5G Wireless WAN

With SpeedFusion Cloud you can utilize traffic steering. A technology whereby connections are controlled based on the application, limiting data wastage and traffic.

Enjoy Speed and Reliability without Having to Compromise

Multi-radio combined with our SpeedFusion Hot Failover technology allows connections of 5G and LTE networks to work simultaneously.

Control Anytime Anywhere

Remote Central Management with private controller or cloud management.

  • B310 5G
    Product CodeBPL-310-5GD-K-T
    WAN Interface1×10/100/1000M Ethernet
    1x USB Interface
    2x Embedded Cellular Modems with
    Redundant SIM Slots
    LAN Interface5×10/1/1000M Ethernet
    2x SFP
    Stateful Firewall Throughput #1 Gbps
    PepVPN Throughput
    (No Encryption)
    600 Mbps
    PepVPN Throughput
    (256-bit AES)
    500 Mbps
    SpeedFusion FeaturesHot Failover, WAN Smoothing,
    Bandwidthing Bonding
    Number of PepVPN SpeedFusion Peers2/30^
    Cellular 1 Data Rate*
    (Downlink/Uplink)
    5G: 4 Gbps / 700 Mbps
    LTE CAT-20: 2 Gbps / 150 Mbps
    Cellular 2 Data Rate*
    (Downlink / Uplink)
    LTE CAT-12: 600 Mbps / 150 Mbps
    Recommended Users50-500
    Cellular Antenna Connector6x SMA Cellular Antenna Connectors
    Power InputDevice: 12V DC
    Power Consumption17 W (nominal), 30 W (max.)
    Dimensions9.9 x 7.1 x 2.0 inches
    252 x 180 x 50 mm
    Weight1.65 kg
    3.6 pounds
    Operating Temperature32°– 104 °F
    0°– 40°C
    Humidity10%–85% (non-condensing)
    CertificationsFCC, CE
    Package Content1x Balance 310 5G
    1x of 12V5A PSU
    1x Power Cord
    4x Rubber Foot
    6x Cellular Antenna

    # Router Throughput and PepVPN/SpeedFusion Throughput is based on Ethernet frame sizes of 1280 or 1518 bytes. Actual performance can vary across different networking environments. Figures apply to the latest hardware revision. The throughput result is tested with DHCP/Static IP WAN.
    * Theoretical maximum data rates
    ^ Requires PrimeCare Subscription, complementary for the first year.

  • WANSupport for PPPoE, Static IP, DHCP
    WAN Link Health Check
    -PING
    -IPv6 Support
    -DNS Lookup
    -HTTP
    Bandwidth Allowance Monitor
    USB 4G/3G Modem Support
    Intelligent Failover
    Support for Dynamic DNS services
    -changeip.com
    -dyndns.org
    -no-ip.org
    -tzo.com
    -DNS-O-Matic
    LANDHCP Server for LAN Clients
    Extended DHCP Option
    DHCP Reservation
    DNS Proxy for LAN Clients
    VLAN on LAN Support
    Load BalancingIntelligent Failover
    Session Persistence
    Per-Service Load Distribution
    Multiple Algorithms
    -Weighted
    -Enforced
    -Persistence
    -Priority
    -Overflow
    -Least Used
    -Lowest Latency
    SecurityDoS Prevention
    Stateful Firewall
    Web Blocking
    Web Filtering Blacklist
    Complete VPN SolutionPepVPN
    Site-to-Site VPN
    -Bandwidth Bonding
    -Hot Failover
    -256-bit AES Encryption
    -Pre-shared Key Authentication
    -Dynamic Routing
    PPTP/L2TP/OpenVPN Server
    -Local User, LDAP, RADIUS, Active Directory Authentication
    IPsec VPN (Network-to-Network)
    -X.509 Certificate Support
    GRE Tunnel (Network-to-Network)
    Advanced QoS User Groups
    -Bandwidth Reservation
    -Individual Bandwidth Limit
    Application Prioritization
    -By User Groups
    -SIP, HTTPS, VPN QoS
    -Custom Application QoS
    NetworkingNAT and IP Forwarding
    Static Routes
    Port Forwarding
    Many to One, One to One NAT
    NAT Pool
    SIP ALG, H.323 ALG
    UPnP, NAT-PMP
    WINS Server
    VRRP HA Support
    BGP, OSPFv2 and RIPv2 Support
    AP Controller Support for Pepwave AP Series
    Auto AP Discovery
    Auto AP Firmware Management
    AP Profile Configuration
    Wi-Fi Usage Statistics
    Captive PortalSupport for Wired and Wireless LAN Clients
    Support RADIUS Authentication
    Support LDAP Authentication
    Time and Usage Quotas on Open Access Mode
    Built-in Customizable Splash Page
    DNSBuilt-in Authoritative DNS

    Support for A, CNAME, NS, MX, PTR, SOA, SRV, TXT records
    Device ManagementWeb Administrative Interface
    Command Line Interface
    InControl Cloud Management
    Email Notification
    Active Client & Session Lists
    Bandwidth Usage Statistics
    Syslog Service
    SNMP v1, v2c and v3
  • Product CodeDescriptionEmbedded ModemsCarrier/Categories5G BandsLTE Bands
    BPL-310-5GD-K-T-PRMBalance 310 5G with
    1x 5G and
    1x LTE CAT-12
    modems
    2Cellular 1:
    Global/5G

    Cellular 2:
    Global*/
    LTE CAT-12
    Cellular 1:
    5G (NSA) Sub 6Ghz:
    n1, n2, n3, n5, n7, n8, n12, n20, n28,
    n38, n41, n66, n71, n77, n78, n79
    Cellular 1:
    B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17,
    B18, B19, B20, B25, B26, B28, B29, B30, B32, B34,
    B38, B39, B40, B41, B42, B46, B48, B66, B71

    Cellular 2:
    B1, B2, B3, B4, B5, B7, B8, B9, B12, B13, B18,
    B19, B20, B26, B28, B29, B30, B32, B41, B42,
    B43, B46, B48, B66
    BPL-310-5GD-R-T-PRMBalance 310 5G with
    1x 5G and
    1x LTE CAT-12
    modems
    2Cellular 1:
    Global/
    5G

    Cellular 2:
    America/
    LTE CAT-12
    Cellular 1:
    5G (NSA) Sub 6Ghz:
    n1, n2, n3, n5, n7, n8, n12, n20, n28,
    n38, n41, n66, n71, n77, n78, n79
    Cellular 1:
    B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17,
    B18, B19, B20, B25, B26, B28, B29, B30, B32, B34,
    B38, B39, B40, B41, B42, B46, B48, B66, B71

    Cellular 2:
    B1, B2, B3, B4, B5, B7, B8, B9, B12, B13, B14,
    B18, B19, B20, B26, B29, B30, B32, B41, B42,
    B43, B46, B48, B66

    * China & HK TD LTE are excluded.

  • Product CodeProduct NameDescription
    PRM-BPL-310-5G-1Y PrimeCare1 Year PrimeCare Subscription
    PRM-BPL-310-5G-2Y PrimeCare2 Year PrimeCare Subscription
    PRM-BPL-310-5G-4Y PrimeCare4 Year PrimeCare Subscription
