Compare Router models
Compare other series? Check Switches and Access Points .
Quick Look
No differences
Number of Ethernet WAN port
1 (2.5G)
1 (GE)
Number of Ethernet WAN port
4 / 6 (GE)
Number of Ethernet WAN port
8 / 9 (2.5G)
Number of Ethernet LAN port
1 (GE)
Number of Ethernet LAN port
2 / 0 (2.5G)
Number of Ethernet LAN port
1 / 0 (10G)
Router Throughput
1Gbps
Router Throughput
1Gbps
Router Throughput
4Gbps
SpeedFusion VPN Throughput (No Encryption)
400Mbps
SpeedFusion VPN Throughput (No Encryption)
400Mbps
SpeedFusion VPN Throughput (No Encryption)
1Gbps
SpeedFusion VPN Throughput (256-bit AES)
200Mbps
SpeedFusion VPN Throughput (256-bit AES)
200Mbps
SpeedFusion VPN Throughput (256-bit AES)
1Gbps
Number of Cellular Modem
No
Number of Cellular Modem
No
Number of Cellular Modem
No
Interfaces
No differences
Maximum Ethernet WAN / LAN port configuration
2 WAN with 1 LAN
Maximum Ethernet WAN / LAN port configuration
6 WAN with 0 LAN
4 WAN with 2 LAN
Maximum Ethernet WAN / LAN port configuration
9 WAN with 0 LAN
8 WAN with 1 LAN
SFP LAN / WAN
No
SFP LAN / WAN
No
SFP LAN / WAN
1x 10G SFP+ WAN/LAN
Serial Interface
No
Serial Interface
Yes (RS-232)
Serial Interface
No
Wi-Fi AP
Yes
Wi-Fi AP
Yes
Wi-Fi AP
Yes
Wi-Fi WAN
Yes
Wi-Fi WAN
Yes
Wi-Fi WAN
No
USB WAN
No
USB WAN
Yes (1x USB)
USB WAN
Yes (2x USB-C)
Module Expansion
No
Module Expansion
No
Module Expansion
No
Performance
No differences
Number of Recommended Users
1–150
Number of Recommended Users
1–150
Number of Recommended Users
50-500
Maximum Number of Controlled AP / Switch
30 / 50 1
50 AP is available as a license add-on (AP-LC-50).
Maximum Number of Controlled AP / Switch
30 / 50 1
50 AP is available as a license add-on (AP-LC-50).
Maximum Number of Controlled AP / Switch
30 / 50 1
50 AP is available as a license add-on (AP-LC-50).
Wireless details
No differences
Cellular Modem Category options
No
Cellular Modem Category options
No
Cellular Modem Category options
No
5G support
No
5G support
No
5G support
No
SIM Slots
No
SIM Slots
No
SIM Slots
No
SIM Card Size
No
SIM Card Size
No
SIM Card Size
No
Wi-Fi Radio
Dual (2.4GHz + 5GHz)
2x2 Wi-Fi 6
Wi-Fi Radio
Dual (2.4GHz + 5GHz)
2x2 Wi-Fi 6
Wi-Fi Radio
Dual (2.4GHz + 5GHz)
2x2 Wi-Fi 7
Wi-Fi Antenna Transmit Power (2.4GHz, single chain)
24dBm
Wi-Fi Antenna Transmit Power (2.4GHz, single chain)
21dBm
Wi-Fi Antenna Transmit Power (2.4GHz, single chain)
24dBm
Wi-Fi Antenna Transmit Power (5GHz, single chain)
26dBm
Wi-Fi Antenna Transmit Power (5GHz, single chain)
22dBm
Wi-Fi Antenna Transmit Power (5GHz, single chain)
23dBm
Multiple SSIDs
16
Multiple SSIDs
16
Multiple SSIDs
16
GPS
Yes
GPS
Yes
GPS
Yes
RemoteSIM (used in SIM Injector)
No
RemoteSIM (used in SIM Injector)
No
RemoteSIM (used in SIM Injector)
No
FusionSIM
No
FusionSIM
No
FusionSIM
No
Peplink eSIM Data Plans
No
Peplink eSIM Data Plans
No
Peplink eSIM Data Plans
No
BYO eSIM
No
BYO eSIM
No
BYO eSIM
No
Features
No differences
SpeedFusion Hot Failover
Yes
SpeedFusion Hot Failover
Yes
SpeedFusion Hot Failover
Yes
SpeedFusion Smoothing
Yes
SpeedFusion Smoothing
Yes
SpeedFusion Smoothing
Yes
SpeedFusion Bandwidth Bonding
Yes
SpeedFusion Bandwidth Bonding
Yes
SpeedFusion Bandwidth Bonding
Yes
SpeedFusion Connect
Yes 2
PrimeCare subscription includes 500GB/year complimentary SpeedFusion Connect Usage data.
SpeedFusion Connect
Yes 2
PrimeCare subscription includes 500GB/year complimentary SpeedFusion Connect Usage data.
SpeedFusion Connect
Yes
SpeedFusion Relay Mode (Server)
Yes
SpeedFusion Relay Mode (Server)
Yes
SpeedFusion Relay Mode (Server)
Yes
Drop-In Mode
Yes
Drop-In Mode
Yes
Drop-In Mode
Yes
High Availability
Yes
High Availability
Yes
High Availability
Yes
Peplink AP Series Management
Yes
Peplink AP Series Management
Yes
Peplink AP Series Management
Yes
Remote AP & Multiple Config Profiles Management
No
Remote AP & Multiple Config Profiles Management
No
Remote AP & Multiple Config Profiles Management
No
Switch Controller
Yes
Switch Controller
Yes
Switch Controller
Yes
WAN as LAN
No
WAN as LAN
Yes
WAN as LAN
Yes
LAN Bypass
No
LAN Bypass
No
LAN Bypass
No
InTouch
Yes
InTouch
Yes
InTouch
Yes
Virtual WAN
Yes
Virtual WAN
Yes
Virtual WAN
Yes
Synergy Mode (Controller)
Yes
Synergy Mode (Controller)
Yes
Synergy Mode (Controller)
Yes
Synergized Device
Yes
Synergized Device
Yes
Synergized Device
Yes
Application and Web Blocking
Yes
Application and Web Blocking
Yes
Application and Web Blocking
Yes
Web Content Filtering
Full
Web Content Filtering
Full
Web Content Filtering
Full
IP Passthrough
Yes
IP Passthrough
Yes
IP Passthrough
Yes
IPv6
No
IPv6
No
IPv6
Yes
x.509 Certificate
Yes
Captive Portal
Yes
Captive Portal
Yes
Captive Portal
Yes
GPIO
Yes
GPIO
Yes
GPIO
No
Ignition Sensing
Yes
Ignition Sensing
Yes
Ignition Sensing
No
Netflow Support
Yes
Netflow Support
Yes
Netflow Support
Yes
LACP (802.3ad) NIC Bonding
No
LACP (802.3ad) NIC Bonding
No
LACP (802.3ad) NIC Bonding
No
Jumbo Frame Support
No
Jumbo Frame Support
No
Jumbo Frame Support
Yes
Internal Storage for Edge Computing
Yes (8GB)
External Storage via USB Port
No
Dead Reckoning
Yes
Dead Reckoning
Yes
Dead Reckoning
Yes
Core Functionality
No differences
Inter-VLAN Routing
Yes
Inter-VLAN Routing
Yes
Inter-VLAN Routing
Yes
802.1q VLANs Supported
16
802.1q VLANs Supported
16
802.1q VLANs Supported
20
Port-Based VLAN
Yes
Port-Based VLAN
Yes
Port-Based VLAN
Yes
Load Balancing Algorithms
8
Load Balancing Algorithms
8
Load Balancing Algorithms
Yes
Load Balancing & Failover
Yes
Load Balancing & Failover
Yes
Load Balancing & Failover
8
Inbound Load Balancing
No
Inbound Load Balancing
No
Inbound Load Balancing
Yes
InControl 2 Cloud Management
Yes
InControl 2 Cloud Management
Yes
InControl 2 Cloud Management
Yes
InControl GPS Fleet Management
Yes
InControl GPS Fleet Management
Yes
InControl GPS Fleet Management
Yes
Advanced QoS Functionality
No differences
Bandwidth Usage Monitoring
Yes
Bandwidth Usage Monitoring
Yes
Bandwidth Usage Monitoring
Yes
QoS for VoIP and E-Commerce
Yes
QoS for VoIP and E-Commerce
Yes
QoS for VoIP and E-Commerce
Yes
User Groups Bandwidth Control
Yes
User Groups Bandwidth Control
Yes
User Groups Bandwidth Control
Yes
VPN Functionality
No differences
SpeedFusion VPN
Yes
SpeedFusion VPN
Yes
SpeedFusion VPN
Yes
Number of SpeedFusion VPN Peers
2 / 5 / 10 / 20
Number of SpeedFusion VPN Peers
2 / 5 / 10 / 20
Number of SpeedFusion VPN Peers
2 or 30
IPsec VPN
Yes
IPsec VPN
Yes
IPsec VPN
Yes
Number of IPsec Tunnels
5
Number of IPsec Tunnels
5
Number of IPsec Tunnels
5
L2TP VPN / Open VPN / PPTP VPN Server
Yes
L2TP VPN / Open VPN / PPTP VPN Server
Yes
L2TP VPN / Open VPN / PPTP VPN Server
Yes
Maximum PPTP / L2TP / OpenVPN Users
3
Maximum PPTP / L2TP / OpenVPN Users
3
Maximum PPTP / L2TP / OpenVPN Users
15
Remote RADIUS / LDAP authentication in Remote User Access
No
Remote RADIUS / LDAP authentication in Remote User Access
No
Remote RADIUS / LDAP authentication in Remote User Access
Yes
Number of OpenVPN Tunnel (Site to Site)
5
Number of OpenVPN Tunnel (Site to Site)
5
Number of OpenVPN Tunnel (Site to Site)
5
Number of GRE Tunnel (Site to Site)
5
Number of GRE Tunnel (Site to Site)
5
Number of GRE Tunnel (Site to Site)
5
Hardware
No differences
Enclosure
Indoor
Metal
Enclosure
Indoor
Metal
Enclosure
Indoor
Metal
4pin Molex Micro-Fit Connector
Yes
4pin Molex Micro-Fit Connector
Yes
4pin Molex Micro-Fit Connector
No
Terminal Block Power Connector for Mobile / Vehicular Deployment
No
Terminal Block Power Connector for Mobile / Vehicular Deployment
No
Terminal Block Power Connector for Mobile / Vehicular Deployment
Yes
AC Adapter or PSU
AC Input 100V–240V
DC Output 12V 2A
AC Adapter or PSU
AC Input 100V–240V
DC Output 12V
AC Adapter or PSU
AC Input 100V – 240V
DC Output 54V 5.19A
Input voltage
DC 10–30V
Input voltage
DC 10–30V
Input voltage
DC 12–54V
PoE Input
Yes
PoE Input
Yes
PoE Input
No
PoE Output
No
PoE Output
No
PoE Output
Up to 8x 802.3at PoE+ 6
A DC input voltage of 50V – 54V is required to enable PoE output.
USB Power Input
No
USB Power Input
No
USB Power Input
No
Nominal Power Consumption
9W
Nominal Power Consumption
11W
Nominal Power Consumption
25W
Maximum Power Consumption
11W
Dimensions in inches
5.78 x 5.08 x 1.15 inches
Dimensions in inches
8.58 x 7.68 x 1.61 inches
Dimensions in inches
7.3 x 8 x 1.61 inches
Dimensions in mm
146.8 x 129 x 29.3 mm
Dimensions in mm
218 x 195 x 29.5 mm
Dimensions in mm
186 x 204.5 x 41 mm
Weight (Pound)
1.21 pounds
Weight (Pound)
2.03 pounds
Weight (Pound)
7.58 pounds
Weight (Gram / Kilogram)
550 grams
Weight (Gram / Kilogram)
924 grams
Weight (Gram / Kilogram)
3.44 kg
Operating Temperature
-40°–149°F
-40°–65°C
Operating Temperature
-40°–149°F
-40°–65°C
Operating Temperature
-40°–149°F
-40°–65°C
Humidity
15%–95% (non-condensing)
Humidity
15%–95% (non-condensing)
Humidity
15%–95% non-condensing
Rack-mount
No
Rack-mount
No
Rack-mount
No
Dual Hot Swap Power Supply
No
Dual Hot Swap Power Supply
No
Dual Hot Swap Power Supply
No
Warranty Info
No differences
Warranty
1-Year Limited Warranty
Warranty
1-Year Limited Warranty
Warranty
1-Year Limited Warranty
