PDX

Portable, Rapidly Deployable SD-WAN

The PDX has a quad-cellular router, antennas, and batteries all seamlessly integrated into a rugged enclosure. For even more cellular connections and frequencies, the PDX is capable of integrating SpeedFusion Engines.

Portable,Instantly Deployable Industrial-Grade SD-WAN Router PDX #2
Portable,Instantly Deployable Industrial-Grade SD-WAN Router PDX #2

Instantly Connect from Anywhere

Redundant SIM Slots

Quad Cellular Modems and Redundant SIM slots allow you to use up to four different cellular providers for bandwidth bonding, data overage protection or eliminating blind spots.

Built Tough

Rated at 7.7G vibration resistance by the military MIL-STD-810H standard. Wide -40° – 113°F (-40° – 45°C) Temperature range.

Battery Powered

The PDX has optional batteries allowing it to operate remotely for up to 9 hours.

Rapid Deployment for Public Safety

Deployable within minutes, the PDX offers Public Safety personnel the ability to establish stable and secure communications to headquarters from any emergency site. Equipped with built-in interfaces for WAN, LAN, and Wi-Fi, as well as antennas for cellular and GPS, the PDX can be used in remote and volatile situations.

Instant Connectivity for Temporary Sites

The PDX provides you with rapid deployment connectivity from the moment boots hit the ground. Combining the bandwidth of up to 4x Gigabit LTE connections, the PDX provides fast and reliable connectivity regardless of site location. Quickly and safely transmit project data, emails, plans, and blueprints between personnel, sites, and headquarters.

Event Live Streaming and Connectivity

Keep your event connected and your cameras streaming. With support for 4x Gigabit LTE connections, the PDX can keep your event connected no matter where it is held. The PDX has 8x 802.3at PoE ports, so you can simplify your cabling when connecting and powering your devices. It can also deliver 802.11ac Wi-Fi which supports a customizable captive portal with advertisements.

Speed & Reliability. Brought by SpeedFusion™

SpeedFusion allows users to combine any number of connections together to form a point-to-point link to achieve what others cannot:

Combine the bandwidth of several mobile connections to form an ultra-fast data link. Sustain bandwidth-hungry and latency sensitive tasks without the need for fixed lines.

Hot Failover maintains secure tunnels over all available WAN links to keep the network up and running when a connection drops out. If a WAN link fails, SpeedFusion instantly routes traffic to a working tunnel for uninterrupted VoIP sessions.

SpeedFusion is carrier agnostic and our products are certified with multiple carriers. By combining the coverage network of several mobile carriers, chances of running into a network blindspot or congestion is minimized.

With the help of WAN smoothing network traffic will be assigned to WAN connection with the lowest latency. Use multiple WAN connections to create a single, jitter-free data stream.

Portable,Instantly Deployable Industrial-Grade SD-WAN Router PDX #7

InControl 2. Powerful Cloud Management Platform

PDX is supported by InControl, Peplinks Cloud-Based SD-WAN Network Management Platform. Setup SpeedFusion networks, make bulk configuration changes, determine Firmware policy, build a custom captive portal. Do all this and more remotely using the InControl2.

  • WAN Interface2x GE Ports*
    4x Embedded LTE-A Modems with Redundant SIM Slots
    LAN Interface7x GE Ports*
    Wi-Fi Interface802.11ac/a/b/g/n, 1166 Mbps 2×2 MIMO Wi-Fi WAN and/or AP Simultaneous Dual-Band
    PDX Throughput2.5 Gbps
    PepVPN Throughput (No Encryption) | (256-bit AES)600 Mbps | 500 Mbps
    Recommended Users50-500
    LTE-A Pro ModemsDownlink/Uplink Per Modem:
    600 Mbps/150 Mbps
    Cellular and GPS Antennas8x Cellular Antennas (Embedded)
    1x GPS Antenna (Embedded)
    4x Wi-Fi Antennas (Embedded)
    Power InputDC: 12V – 56V, AC: 100V – 240V
    Power OutputUp to 7x 802.3af PoE, 1x USB Power Outputs
    Power Consumption38W (max.)
    Dimensions19.7 x 14.8 x 7.7 inches |
    500 x 375 x 195 mm
    Weight28.7 pounds | 13 kg
    Operating Temperature-40° – 113°F |
    -40° – 45°C
    Humidity15% – 95% (non-condensing)
    CertificationsFCC, IC, CE,
    7.7G Vibration resistance, MIL-STD-810H 514.8E-1 Cat24, IP55/65^, [email protected], FirstNet%
    Warranty1-Year Limited Warranty



    * 2x GE port is configured as a LAN port by default, configuration is changeable on the Web Admin. ^ IP55 certified. IP65 certification testing in progress.

    ^ IP55 certified. IP65 certification testing in progress.

    @ Certification Pending.

    % Tests completed, under FirstNet final review.

  • WANSupport for PPPoE, Static IP, DHCP
    WAN Link Health Check
    -PING
    -DNS Lookup
    -HTTP
    Bandwidth Allowance Monitor
    IPv6 Support
    USB 4G/3G Modem Support
    Support for Dynamic DNS services
    -changeip.com
    -dyndns.org
    -no-ip.org
    -tzo.com
    -DNS-O-Matic
    WAN Port Convertible into LAN Port
    LANDHCP Server for LAN Clients
    Extended DHCP Option
    DHCP Reservation
    DNS Proxy for LAN Clients
    VLAN on LAN Support
    Load BalancingIntelligent Failover
    Session Persistence
    Per-Service Load Distribution
    Multiple Algorithms
    -Weighted
    -Enforced
    -Persistence
    -Priority
    -Overflow
    -Least Used
    -Lowest Latency
    SecurityDoS Prevention
    Stateful Firewall
    Web Blocking
    Web Filtering Blacklist
    Complete VPN SolutionPepVPN
    -Site-to-Site VPN
    -Bandwidth Bonding
    -Hot Failover
    -256-bit AES Encryption
    -Pre-shared Key Authentication
    -Dynamic Routing
    PPTP/L2TP/OpenVPN Server
    -Local User, LDAP, RADIUS, Active Directory Authentication
    IPsec VPN (Network-to-Network)
    -X.509 Certificate Support
    GRE Tunnel (Network-to-Network)
    Advanced QoS User Groups
    -Bandwidth Reservation
    -Individual Bandwidth Limit
    Application Prioritization
    -By User Groups
    -SIP, HTTPS, VPN QoS
    -Custom Application QoS
    NetworkingNAT and IP Forwarding
    Static Routes
    Port Forwarding
    Many to One, One to One NAT
    NAT Pool
    SIP ALG, H.323 ALG
    UPnP, NAT-PMP
    WINS Server
    VRRP HA Support
    BGP, OSPFv2 and RIPv2 Support
    AP Controller Auto AP Discovery
    Auto AP Firmware Management
    AP Profile Configuration
    Wi-Fi Usage Statistics
    Captive PortalSupport for Wired and Wireless LAN Clients
    Support RADIUS Authentication
    Time and Usage Quotas on Open Access Mode
    Built-in Customizable Splash Page
    Device ManagementWeb Administrative Interface
    Command Line Interface
    InControl Cloud Management
    Email Notification
    Active Client & Session Lists
    Bandwidth Usage Statistics
    Syslog Service
    SNMP v1, v2c and v3
    Power RequirementsDC Jack: 12V – 56V
    • PDX
    • 1x Special Power Cord for PDX
    • 1x Special Card Plug for PDX
  •

    Product Code

    Description
    PDX-BAT-KIT     Pepwave PDX Battery Kit, 1x Metal Clamp, 1x Power Cable, 2x M3 Scr, 98Wh, 14.4V
    SFE-PDX-KIT

    SpeedFusion Engine Duo Accessory Kit for PDX



  • Product CodeCarrier/RegionEmbedded Modems4G Bands3G Bands
    PDX-LTEA-R-TAmerica / CAT-124B1, B2, B3, B4, B5, B7, B8, B9, B12, B13, B14 , B18, B19, B20, B26, B29, B30, B32, B41, B42, B43, B46, B48, B66B1, B2, B4, B5, B6, B8, B9, B19
    PDX-LTEA-K-TGlobal / CAT-124B1, B2, B3, B4, B5, B7, B8, B9, B12, B13, B18, B19, B20, B26, B28 , B29, B30, B32, B41, B42, B43, B46, B48, B66B1, B2, B4, B5, B6, B8, B9, B19
