Small is the new mighty.

Bring your deployments to life with the versatility of the MBX Mini. It’s just as brilliant as any other MBX device we have to offer. So connect your devices to the PoE enabled LAN ports to provide network simplicity as well as IEEE 802.1X port authentication. This MBX Mini has the power to achieve it all.

Keep your connection flowing in whatever deployment that you’re immersed in and deliver more power and redundancy with THREE power input options: AC, DC, and USB-C.

One. Two. Three. Four.

We know fast connections are critical to achieving great things. Its dual-band Wi-Fi and 5G capabilities ensure you experience the fastest available network. If the dual embedded cellular WANs are not enough, the MBX Mini can be expanded to FOUR cellular WANs by simply connecting it to our MAX Adapters via the dual USB ports.

Making hard to manage feel like hardly managing.

With this FusionSIM-ready router, you can say goodbye to switching and managing multiple SIMs via the router. FusionSIM offers remote provisioning of SIM profiles from anywhere in the world. Managing made easy, ready when you are!

  • WANSupport for PPPoE, Static IP, DHCP
    WAN Link Health Check
    PING
    IPv6 Support
    DNS Lookup
    HTTP
    Bandwidth Allowance Monitor
    USB 4G/3G Modem Support
    Intelligent Failover
    Support for Dynamic DNS services
    changeip.com
    dyndns.org
    no-ip.org
    tzo.com
    DNS-O-Matic
    LANDHCP Server for LAN Clients
    Extended DHCP Option
    DHCP Reservation
    DNS Proxy for LAN Clients
    VLAN on LAN Support
    Per-Port VLAN Support
    Load BalancingIntelligent Failover
    Session Persistence
    Per-Service Load Distribution
    Multiple Algorithms
    Weighted
    Enforced
    Persistence
    Priority
    Overflow
    Least Used
    Lowest Latency
    Fastest Response Time
    Complete VPN SolutionPepVPN
    Site-to-Site VPN
    Bandwidth Bonding
    Hot Failover
    256-bit AES Encryption
    Pre-shared Key Authentication
    Dynamic Routing
    PPTP VPN Server
    RADIUS, LDAP Authentication
    IPsec VPN (Network-to-Network)
    X.509 Certificate Support
    Advanced QoSUser Groups
    Bandwidth Reservation
    Individual Bandwidth Limit
    Application Prioritization
    By User Groups
    SIP, HTTPS, VPN QoS
    Custom Application QoS
    NetworkingNAT and IP Forwarding
    Static Routes
    Port Forwarding
    Many to One, One to One NAT
    NAT Pool
    SIP ALG, H.323 ALG
    UPnP, NAT-PMP
    WINS Server
    VRRP HA Support
    BGP, OSPFv2 and RIPv2 Support
    AP ControllerAuto AP Discovery
    Auto AP Firmware Management
    AP Profile Configuration
    Wi-Fi Usage Statistics
    SecurityDoS Prevention
    Stateful Firewall
    Web Blocking
    Web Filtering Blacklist
    Captive PortalSupport for Wired and Wireless LAN Clients
    Support RADIUS Authentication
    Time and Usage Quotas on Open Access Mode
    Built-in Customizable Splash Page
    Device ManagementWeb Administrative Interface
    Command Line Interface
    InControl Cloud Management
    Email Notification
    Active Client & Session Lists
    Bandwidth Usage Statistics
    Syslog Service
    SNMP v1, v2c and v3
  • Product CodeEmbedded ModemsRegions 5G Bands LTE Bands
    MAX-MBX-MINI-5GD-T2x 5GPrimary: APAC, EMEA
    Compatibility: Global
    5G (NSA) Sub 6Ghz:
    n1, n2, n3, n5, n7, n8, n12,
    n20, n28, n38, n41, n66,
    n71, n77, n78, n79
    B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17,
    B18, B19, B20, B25, B26, B28, B29, B30, B32,
    B34, B38, B39, B40, B41, B42, B46, B48, B66,
    B71
    MAX-MBX-MINI-5GH-T2x 5GPrimary: North America*
    Compatibility: Global
    5G (NSA) Sub 6Ghz:
    n1, n2, n3, n5, n28, n41, n66,
    n71, n77, n78, n79

    5G (SA) Sub 6Ghz:
    n77, n78, n79
    B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17,
    B18, B19, B20, B25, B26, B28, B29, B30, B32,
    B34, B38, B39, B40, B41, B42, B46, B48, B66,
    B71

    *US Carrier Certification: AT&T, Verizon(Pending).

    • MBX Mini, PSU 180W (ACW-630)
    • 4x Dual-Band Wi-Fi Antennas (ACW-341)
    • 1x QMA to SMA Adapter (for GPS)
    • 1x GPS Antenna (ACW-232)
    • Power Cord
    • 1 Pair of Ear L-Mounts kit (ACW-731)
    • Screw set of Ear L-Mounts kit
    • 3pin Terminal Block Connector (Ignition Sense)
    • 4pin Terminal Block Connector (Power Supply)
    • Rubber Foot Pad set

    *Cellular antennas not included. To enhance the MBX Mini, Mobility and Maritime antennas are recommended.

  • Product CodeDescription
    ANT-MR-40G-S-W-64X4 MIMO 5G-Ready Maritime Antenna with GPS Receiver (White/ SMA / 6.5 ft / 2 m)
    ANT-MB-42G-Q-W-17-in-1 Cellular and Wi-Fi Antenna System with GPS Receiver (White / QMA / 1 ft / 0.3 m)
    ANT-MB-42G-Q-B-17-in-1 Cellular and Wi-Fi Antenna System with GPS Receiver (Black / QMA / 1 ft / 0.3 m)
    ANT-MB-42G-Q-W-67-in-1 Cellular and Wi-Fi Antenna System with GPS Receiver (White / QMA / 6.5 ft / 2 m)
    ANT-MB-42G-Q-B-67-in-1 Cellular and Wi-Fi Antenna System with GPS Receiver (Black / QMA / 6.5 ft / 2 m)
