Balance 20

Advanced Dual-WAN Router for an affordable price

The Peplink Balance 20 supports dual-wan connectivity, switching between the 2 GE WAN links is automatic and seamless.

150Mbps Dual-WAN Router Balance 20 #12
150Mbps Dual-WAN Router Balance 20 #12

Balance 20.

Affordable Multi-WAN Router.

150Mbps Dual-WAN Router Balance 20 #2
  • 60 Users
  • 150Mbps Throughput
  • 2 WAN Ports
  • 5 VPN Peers

There’s a Perfect Balance for Every Situation

Peplink ‘s line of products includes features that make your enterprise deployment easier and increase your network reliability and security in several ways. Boost network data rates, reliability, and flexibility while slashing connectivity costs with Peplink SD-WAN technology designed for multi-WAN link load balancing. Use Load Balancing and SpeedFusion bandwidth bonding to deliver superfast VoIP, video streaming, and data using an SD-WAN enabled network.

  • Branch/Small Office
  • Small Business
  • Mid-Size Business
  • Large Enterprise/Campus
  • Cloud/VM
150Mbps Dual-WAN Router Balance 20 #3

Built to Last

Capable of years of uptime, the Balance  series easily handles monthly bandwidth that would crush lesser equipment. Every Peplink design is rigorously tested to exceed your expectations for speed, reliability, durability, and ease-of-use. We invest heavily in quality assurance and user experience testing to give you affordable, enterprise-class gear that just works, from the moment you take it out of the box.

InControl 2. Powerful Cloud Management Platform

Balance 20  is supported by InControl, Peplinks Cloud-Based SD-WAN Network Management Platform, which lets you provision, monitor, and manage your routers. All from a single screen.

150Mbps Dual-WAN Router Balance 20 #4

Web Admin Demo

Experience powerful features of Balance Series web admin online demo.

Note: This is for demonstration purposes only and may differ from our latest UI. Functionality also varies amongst models.

Administrator Username and Password: admin / admin
Read-only Username and Password: user / user

#PowerofPeplink

  • CodeBPL-021
    Ethernet WAN Ports2 (GE)+
    LAN Ports4(GE)
    USB WAN Modem Port1
    Recommended Users [2]1-60
    Stateful Firewall Throughput150Mbps
    802.1q VLANs Supported16
    Port-Based VLANYes
    Load Balancing & FailoverYes
    Load Balancing Algorithms8
    InControl Cloud ManagementYes
    PepVPNYes %
    Number of PepVPN/SpeedFusion Peers [4]2/5 !
    PepVPN Throughput (256-bit AES) [3] 30Mbps
    PepVPN Throughput (No Encryption) [3]60Mbps
    IPsec VPN (Network-to-Network) [5]Yes
    Number of IPsec Tunnels2
    L2TP VPN ServerYes
    PPTP VPN ServerYes
    Recommended L2TP/PPTP Users15
    Pepwave AP Series ManagementYes
    Maximum Number of AP Supported10
    Bandwidth Usage MonitorYes
    QoS for VoIP and ecommerceYes
    User Groups Bandwidth Control Yes
    Web BlockingYes
    Operating Temperature-40° – 149°F | -40° – 65°C
    Power Consumption15W
    Dimensions, Height x Width x Depth3,5 x 26 x 13,3 cm | 1.38 x 10.2 x 5.24 inches
    Weight1 kg (2.2 pounds)
    Certifications FCC, CE, RoHS
    Warranty1-Year Limited Warranty
    Package ContentBalance Router
    12V2A Power Supply (ACW-601)

    [1] For a list of supported modems, please refer to https://www.peplink.com/technology/4g3g-modem-support/.
    [2] Recommendation for sizing purposes only. No software restrictions applied.
    [3] Router Throughput and PepVPN/SpeedFusion Throughput is based on Ethernet frame sizes of 1280 or 1518 bytes. Actual performance can vary across different networking environments. Figures apply to the latest hardware revision.
    [4] Number of peer Peplink or Pepwave devices you can connect using SpeedFusion VPN.
    [5] IPsec only supports connection with Cisco, Juniper, Peplink or Pepwave devices.
    [6] Balance 20/30 LTE/One/210/310 comes with AP Controller Standard, which supports up to two configuration profiles with multiple SSIDs, meaning that all APs will share the same configuration, and you can only manage APs on the local physical LAN. Balance 305/380/580/710/1350/2500 comes with AP Controller Pro, which supports multiple configuration profiles with multiple SSIDs, and you can manage remote APs outside the local physical LAN.
    + Balance 20 and 210 have an extra WAN port which can be activated through license key. Click here to learn more.
    % Balance 20/30 LTE requires firmware 6.1 to support PepVPN.
    ! 2 PepVPN Peers are enabled by default. Can be increased to 5 Peers using license PVN-LC-05.

  • Product CodeProduct NameDescription
    BPL-021-LC-WANWAN Port Activation LicenseActivate WAN 3 on Balance 20
    PVN-LC-05PepVPN License Key for Velocity and BR1 familyEnables up to 5 PepVPN connections
  • Product CodeModelDescription
    BPL-021Balance 20
    2x GE WAN ports and 4x GE LAN ports.
