Specifications
No differences
RJ45 interface
8x 10GE (802.3bt Type 4 PoE++)
RJ45 interface
16x 1GE (802.3at PoE+)
8x 2.5GE (802.3at PoE+)
RJ45 interface
32x 1GE (802.3at PoE+)
16x 2.5GE (802.3at PoE+)
SFP / SFP+ interface
4x 10G SFP+
SFP / SFP+ interface
4x 10G SFP+
SFP / SFP+ interface
4x 10G SFP+
VLAN Groups
Yes
VLAN Groups
Yes
VLAN Groups
Yes
Switch Capacity
240 Gbps
Switch Capacity
152 Gbps
Switch Capacity
224 Gbps
Maximum Packet Forwarding Rate
179 Mpps
Maximum Packet Forwarding Rate
216 Mpps
Maximum Packet Forwarding Rate
318 Mpps
MAC Address Table
32000
MAC Address Table
16000
MAC Address Table
32000
Inter-VLAN Routing
Yes
Inter-VLAN Routing
Yes
Inter-VLAN Routing
Yes
Power Supply Unit
1x Internal PSU (900W)
Power Supply Unit
1x Internal PSU (480W)
Power Supply Unit
1x Internal PSU (900W)
Power Input
1x 100V – 240V AC
Power Input
1x 100V – 240V AC
Power Input
1x 100V – 240V AC
Power Consumption
53W (System)
Power Consumption
38W (System)
Power Consumption
64W (System)
Total PoE Power Budget
720W
Total PoE Power Budget
410W
Total PoE Power Budget
740W
Dimensions in inches (D x W x H)
9.1 x 13.0 x 1.8 inches
Dimensions in inches (D x W x H)
10.3 x 17.3 x 1.8 inches
Dimensions in inches (D x W x H)
12.2 x 17.3 x 1.8 inches
Dimensions in mm (D x W x H)
230 x 330 x 44 mm
Dimensions in mm (D x W x H)
260 x 440 x 45 mm
Dimensions in mm (D x W x H)
310 x 440 x 45 mm
Weight (Pound)
6.4 pounds
Weight (Pound)
9.0 pounds
Weight (Pound)
10.8 pounds
Weight (Kilogram)
2.9 kg
Weight (Kilogram)
4.1 kg
Weight (Kilogram)
4.9 kg
Operating Temperature
32°F – 122°F
0°C – 50°C
Operating Temperature
32°F – 122°F
0°C – 50°C
Operating Temperature
32°F – 122°F
0°C – 50°C
Humidity
15% – 95% (non-condensing)
Humidity
15% – 95% (non-condensing)
Humidity
15% – 95% (non-condensing)
Warranty
1-Year Limited Warranty
Warranty
1-Year Limited Warranty
Warranty
1-Year Limited Warranty
