BR2 Pro
Diseñado para profesionales, por profesionales.
Más rápido, más amplio, más fuerte
El BR2 Pro no solo está diseñado para ser resistente. Sus conexiones duales 5G, Wi-Fi 6 y entrada PoE garantizan una conexión inquebrantable en cualquier escenario.
Tranquilidad total
Con tantas opciones WAN, el BR2 Pro puede realizar conmutación automática sin interrupciones para asegurar el flujo de datos, incluso en las circunstancias más críticas. Su velocidad de enrutamiento Gigabit y el puerto serial para OOBM permiten versatilidad en cualquier implementación SD-WAN.
Oh, cuántas WANs
Complemente cualquier implementación SD-WAN con sus WANs Ethernet duales, 5G/LTE duales, USB WAN y Wi-Fi WAN. ¿No son suficientes WANs? Agregue el MAX Adapter 5G para una tercera conexión 5G al instante. Literalmente, todos los WANs para mantenerlo en marcha.
Diseñado para aplicaciones en vehículos
Asegure su fuente de energía en entornos móviles con el conector de alimentación Molex Micro-Fit. Su amplio rango de entrada de energía junto con las capacidades de Ignition Sensing lo convierten en la opción ideal para instalaciones en vehículos.
Extensión celular sin esfuerzo
Con la función de entrada PoE, el BR2 Pro puede ampliar sin problemas su infraestructura SD-WAN existente para ofrecer conectividad LTE/5G dual. Un solo cable para energía y datos, así de simple.
SIM-pleza como siempre
Con eSIM integrada y soporte para SIM Injector, el BR2 Pro maximiza sus posibilidades con una gestión de SIM flexible y remota.
¡Ejecutar aplicaciones ahora es más fácil!
¿Quiere ejecutar aplicaciones de terceros directamente en su MAX BR2 Pro? ¡Ahora puede! Con edge computing mediante Docker y Python*, las posibilidades son infinitas.
* Disponible en el firmware 8.3.0.
Ver el video
Puertos y conexiones
Descripción general del producto y tabla comparativa
Análisis detallado
| Software | Peplink MAX Firmware |
|---|---|
| WAN | Support for PPPoE, Static IP, DHCP WAN Link Health Check Bandwidth Allowance Monitor Support for Dynamic DNS services WAN Port Convertible into LAN Port |
| LAN | DHCP Server for LAN Clients Extended DHCP Option DHCP Reservation DNS Proxy for LAN Clients VLAN on LAN Support |
| Load Balancing | Multiple Outbound Policy Algorithms • Weighted Balance • Priority • Overflow • Persistence • Least Used • Lowest Latency • Enforced • Fastest Response Time |
| Security | Stateful Firewall DoS Prevention Web Blocking |
| Complete VPN Solution | SpeedFusion VPN • Site-to-Site VPN • 256-bit AES Encryption • Pre-shared Key Authentication • Dynamic Routing X.509 Certificate Support * IPsec VPN (Network-to-Network) ^ Remote User Access (PPTP/L2TP/OpenVPN) |
| Edge Computing | Support on Applications and Docker |
| Advanced QoS | Individual Bandwidth Limit Application Prioritization • SIP, HTTPS, VPN QoS • Custom Application QoS |
| Global Positioning System | Integrated GPS Device Location Map Location Tracking Data with InControl 2 Fleet Management with InControl 2 |
| Networking | NAT and IP Forwarding Static Routes Port Forwarding Many to One, One to One NAT NAT Pool SIP ALG, H.323 ALG UPnP, NAT-PMP |
| AP Controller | Support for Peplink AP Series Auto AP Discovery Auto AP Firmware Management AP Profile Configuration Wi-Fi Usage Statistics |
| Captive Portal Support | Support for Wired LAN clients Support RADIUS Authentication Time and Usage Quotas on Open Access Mode Built-in Customizable Splash Page |
| Device Management | Web Administrative Interface Command Line Interface InControl 2 Cloud Management Email Notification Active Client & Session Lists Bandwidth Usage Statistics Syslog Service SNMP v1, v2c and v3 |
Información de pedido
| Product Code | Embedded Modem | Region | 5G Bands | LTE Bands |
|---|---|---|---|---|
| MAX-BR2-PRO-5GD-T-PRM | 2x 5G | Global | 5G (NSA) Sub 6Ghz: n1, n2, n3, n5, n7, n8, n12, n20, n28, n38, n41, n66, n71, n77, n78, n79 | B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B34, B38, B39, B40, B41, B42, B46, B48, B66, B71 |
| MAX-BR2-PRO-5GN-T-PRM | 2x 5G | Global* *US Carrier Certifications: AT&T, T-Mobile, Verizon, FirstNet | 5G (NSA & SA) Sub 6Ghz: n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n38, n40, n41, n48, n66, n70, n71, n75, n76, n77, n78, n79 | B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B34, B38, B39, B40, B41, B42, B43, B46, B48, B66, B71 |
| MAX-BR2-PRO-5GK-T-PRM | 2x 5G | Global* *US Carrier Certifications: AT&T, T-Mobile, Verizon, FirstNet | 5G (NSA & SA) Sub 6Ghz: n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n38, n40, n41, n48, n66, n71, n75, n76, n77, n78, n79 | B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B34, B38, B39, B40, B41, B42, B43, B46, B48, B66, B71 |
Opiniones de usuarios
“The products are rugged and perform well. The ability to connect to multiple data paths, and then prioritize how the paths are used based on cost and performance, is key to getting what we want out of a mobile router. Great reliability in handy form factor”
– Ecommerce Customer Feedback
Complementos destacados
| Product Code | Descriptions |
|---|---|
| PRM-E-1Y | PrimeCare E (1-Year) |
| PRM-E-2Y | PrimeCare E (2-Year) |
| PRM-E-4Y | PrimeCare E (4-Year) |
| PCP-E-1Y | PrimeCare+ E (1-Year) |
| PCP-E-2Y | PrimeCare+ E (2-Year) |
| PCP-E-4Y | PrimeCare+ E (4-Year) |
| ACW-111 | PoE Adapter |
| ACW-622 | PoE+ Activation Kit |
| ACW-634 | 10ft DC Power Cable |
| ACW-643 | Vehicle Cigarette to Molex Power Cable |
| ACW-791 | Peplink 4-Pin to USB-C Power Cable |
| ANT-SLM-40G-S-B-6 | Slim 40G - 4x4 MIMO 5G Ready Cellular Antenna System with GPS (Black) |
| ANT-MB-42G-S-W-6 | Mobility 42G - 4x4 MIMO 5G Ready Cellular and Wi-Fi Antenna System with GPS (White) |
| ANT-MB-42G-S-B-6 | Mobility 42G - 4x4 MIMO 5G Ready Cellular and Wi-Fi Antenna System with GPS (Black) |
| ANT-MB-82G-S-W-6 | Mobility 82G - 8x8 MIMO 5G Ready Cellular and Wi-Fi Antenna System with GPS (White) |
Contenido del paquete
- 1x MAX BR2 Pro
- 1x 12V3A 4-Pin Power Supply (ACW-663)
- 8x LTE/5G Antennas (ACW-235)
- 2x Dual Band Wi-Fi Antennas (ACW-341)
- 1x GPS Antenna (ACW-232)
