Compare Router models
Compare other series? Check
SD Switches and AP One .
.png)
Quick Look
No differences
Number of Ethernet WAN port
1 / 0 (GE) 2
WAN port(s) can be configured as LAN port(s) via the Web Admin.
Number of Ethernet WAN port
2 (GE)
Number of Ethernet LAN port
1 / 2 (GE) 2
WAN port(s) can be configured as LAN port(s) via the Web Admin.
Number of Ethernet LAN port
4 (GE)
Router Throughput
1Gbps
Router Throughput
1Gbps
Router Throughput
1Gbps
SpeedFusion VPN Throughput (No Encryption)
400Mbps
SpeedFusion VPN Throughput (No Encryption)
400Mbps
SpeedFusion VPN Throughput (No Encryption)
400Mbps
SpeedFusion VPN Throughput (256-bit AES)
200Mbps
SpeedFusion VPN Throughput (256-bit AES)
200Mbps
SpeedFusion VPN Throughput (256-bit AES)
200Mbps
Number of Cellular Modem
2
Number of Cellular Modem
2
Number of Cellular Modem
1
Interfaces
No differences
Maximum Ethernet WAN / LAN port configuration
2 WAN with 4 LAN
1 WAN with 5 LAN
Maximum Ethernet WAN / LAN port configuration
1 WAN with 1 LAN
0 WAN with 2 LAN
Maximum Ethernet WAN / LAN port configuration
2 WAN with 4 LAN
SFP LAN / WAN
No
SFP LAN / WAN
No
SFP LAN / WAN
No
Serial Interface
Yes (RS232)
Serial Interface
Yes (RS-232)
Serial Interface
No
Wi-Fi AP
Yes
Wi-Fi AP
Yes
Wi-Fi AP
Yes
Wi-Fi WAN
Yes
Wi-Fi WAN
Yes
Wi-Fi WAN
Yes
USB WAN
Yes (1x USB)
USB WAN
No
USB WAN
Yes (1x USB-C)
Module Expansion
No
Module Expansion
No
Module Expansion
No
Performance
No differences
Number of Recommended Users
1–150
Number of Recommended Users
25–150
Number of Recommended Users
1–150
Wireless details
No differences
Cellular Modem Category options
2x 5G
Cellular Modem Category options
1x CAT-7 + 1x CAT-12
2x CAT-7
2x CAT-12
Cellular Modem Category options
1x 5G
5G support
Yes
5G support
No
5G support
Yes
SIM Slots
4
SIM Slots
4
SIM Slots
2
SIM Card Size
Nano-SIM (4FF)
SIM Card Size
Nano-SIM (4FF)
SIM Card Size
Nano-SIM (4FF)
Wi-Fi Radio
Dual (2.4GHz + 5GHz)
2x2 Wi-Fi 6
Wi-Fi Radio
Dual (2.4GHz + 5GHz)
2x2 Wi-Fi 6
Wi-Fi Radio
Dual (2.4GHz + 5GHz)
2x2 Wi-Fi 6
Wi-Fi Antenna Transmit Power (2.4GHz, single chain)
21dBm
Wi-Fi Antenna Transmit Power (2.4GHz, single chain)
21dBm
Wi-Fi Antenna Transmit Power (2.4GHz, single chain)
20dBm
Wi-Fi Antenna Transmit Power (5GHz, single chain)
22dBm
Wi-Fi Antenna Transmit Power (5GHz, single chain)
22dBm
Wi-Fi Antenna Transmit Power (5GHz, single chain)
24dBm
Multiple SSIDs
16
Multiple SSIDs
16
Multiple SSIDs
16
GPS
Yes
GPS
Yes
GPS
No
RemoteSIM (used in SIM Injector)
Yes (HW2+)
RemoteSIM (used in SIM Injector)
Yes
RemoteSIM (used in SIM Injector)
Yes (HW2+)
FusionSIM
Yes (HW2+)
FusionSIM
Yes
FusionSIM
Yes (HW2+)
Peplink eSIM Data Plans
Yes
Features
No differences
SpeedFusion Hot Failover
Yes
SpeedFusion Hot Failover
Yes 8
Require PrimeCare Subscription, complimentary for the first year.Enabled by default after Firmware 8.5.0
SpeedFusion Smoothing
Yes
SpeedFusion Smoothing
Yes 8
Require PrimeCare Subscription, complimentary for the first year.Enabled by default after Firmware 8.5.0
SpeedFusion Bandwidth Bonding
Yes
SpeedFusion Bandwidth Bonding
Yes 8
Require PrimeCare Subscription, complimentary for the first year.Enabled by default after Firmware 8.5.0
SpeedFusion Bandwidth Bonding
Yes 9
Require PrimeCare Subscription, complimentary for the first year.
SpeedFusion Connect
Yes 10
PrimeCare subscription includes 1TB/year complimentary SpeedFusion Connect Usage data.
SpeedFusion Connect
Yes 10
PrimeCare subscription includes 1TB/year complimentary SpeedFusion Connect Usage data.
SpeedFusion Connect
Yes 11
PrimeCare subscription includes 500GB/year complimentary SpeedFusion Connect Usage data.
SpeedFusion Relay Mode (Server)
Yes
SpeedFusion Relay Mode (Server)
Yes
SpeedFusion Relay Mode (Server)
Yes
Drop-In Mode
Yes
Drop-In Mode
Yes
Drop-In Mode
Yes
High Availability
Yes
High Availability
Yes
High Availability
Yes
Peplink AP Series Management
Yes
Peplink AP Series Management
Yes
Peplink AP Series Management
Yes
Remote AP & Multiple Config Profiles Management
No
Remote AP & Multiple Config Profiles Management
No
Remote AP & Multiple Config Profiles Management
No
WAN as LAN
Yes
WAN as LAN
Yes
WAN as LAN
No
LAN Bypass
No
LAN Bypass
No
LAN Bypass
No
InTouch
Yes
InTouch
Yes
InTouch
Yes
Virtual WAN
Yes 12
1 Virtual WAN complimentary with active PrimeCare. Up to 3 Virtual WAN upon purchasing Virtual WAN Activation Licence.
Virtual WAN
Yes 12
1 Virtual WAN complimentary with active PrimeCare. Up to 3 Virtual WAN upon purchasing Virtual WAN Activation Licence.
Virtual WAN
Yes 12
1 Virtual WAN complimentary with active PrimeCare. Up to 3 Virtual WAN upon purchasing Virtual WAN Activation Licence.
Synergy Mode (Controller)
Yes
Synergy Mode (Controller)
Yes
Synergy Mode (Controller)
Yes
Synergized Device
Yes
Synergized Device
Yes
Synergized Device
Yes
Application and Web Blocking
Yes
Application and Web Blocking
Yes
Application and Web Blocking
Yes
Web Content Filtering
Lite
Web Content Filtering
Lite
Web Content Filtering
Lite
IP Passthrough
Yes
IPv6
No
IPv6
Yes
IPv6
No
x.509 Certificate
Yes
Captive Portal
Yes
Captive Portal
Yes
Captive Portal
Yes
GPIO
Yes
GPIO
Yes
GPIO
Yes
Ignition Sensing
Yes
Ignition Sensing
Yes
Ignition Sensing
No
Netflow support
Yes
Netflow support
Yes
Netflow support
Yes
LACP (802.3ad) NIC Bonding
No
LACP (802.3ad) NIC Bonding
No
Internal Storage for Edge Computing
No
External Storage via USB Port
No
External Storage via USB Port
Yes 18
Require software add-on licence and Firmware 8.5.2 or above to enable edge computing (Docker).
Dead Reckoning
Yes
Dead Reckoning
No
Dead Reckoning
No
Core Functionality
No differences
Inter-VLAN Routing
Yes
Inter-VLAN Routing
Yes
Inter-VLAN Routing
Yes
802.1q VLANs Supported
16
802.1q VLANs Supported
128
802.1q VLANs Supported
16
Port-Based VLAN
Yes
Port-Based VLAN
Yes
Port-Based VLAN
Yes
Load Balancing Algorithms
8
Load Balancing Algorithms
8
Load Balancing Algorithms
8
Load Balancing & Failover
Yes
Load Balancing & Failover
Yes
Load Balancing & Failover
Yes
Inbound Load Balancing
No
Inbound Load Balancing
No
Inbound Load Balancing
No
InControl 2 Cloud Management
Yes
InControl 2 Cloud Management
Yes
InControl 2 Cloud Management
Yes
InControl GPS Fleet Management
Yes
InControl GPS Fleet Management
Yes
InControl GPS Fleet Management
No
Advanced QoS Functionality
No differences
Bandwidth Usage Monitoring
Yes
Bandwidth Usage Monitoring
Yes
Bandwidth Usage Monitoring
Yes
QoS for VoIP and E-Commerce
Yes
QoS for VoIP and E-Commerce
Yes
QoS for VoIP and E-Commerce
Yes
User Groups Bandwidth Control
Yes
User Groups Bandwidth Control
Yes
User Groups Bandwidth Control
Yes
VPN Functionality
No differences
SpeedFusion VPN
Yes
SpeedFusion VPN
Yes
SpeedFusion VPN
Yes
Number of SpeedFusion VPN Peers
2 or 5 19
2 SpeedFusion VPN Peers are enabled by default. 5 SpeedFusion VPN Peers are enabled with PrimeCare Subscription, complimentary for the first year.
Number of SpeedFusion VPN Peers
2 or 5 19
2 SpeedFusion VPN Peers are enabled by default. 5 SpeedFusion VPN Peers are enabled with PrimeCare Subscription, complimentary for the first year.
Number of SpeedFusion VPN Peers
2 or 5 19
2 SpeedFusion VPN Peers are enabled by default. 5 SpeedFusion VPN Peers are enabled with PrimeCare Subscription, complimentary for the first year.
IPsec VPN
Yes
IPsec VPN
Yes
IPsec VPN
Yes
Number of IPsec Tunnels
5
Number of IPsec Tunnels
5
Number of IPsec Tunnels
5
L2TP VPN / Open VPN / PPTP VPN Server
Yes
L2TP VPN / Open VPN / PPTP VPN Server
Yes
L2TP VPN / Open VPN / PPTP VPN Server
Yes
Maximum PPTP / L2TP / OpenVPN Users
3
Maximum PPTP / L2TP / OpenVPN Users
3
Maximum PPTP / L2TP / OpenVPN Users
3
Remote RADIUS / LDAP authentication in Remote User Access
No
Remote RADIUS / LDAP authentication in Remote User Access
No
Remote RADIUS / LDAP authentication in Remote User Access
No
Number of OpenVPN Tunnel (Site to Site)
5
Number of OpenVPN Tunnel (Site to Site)
5
Number of OpenVPN Tunnel (Site to Site)
5
Number of GRE Tunnel (Site to Site)
5
Number of GRE Tunnel (Site to Site)
5
Number of GRE Tunnel (Site to Site)
5
Hardware
No differences
Enclosure
Indoor
Metal
Enclosure
Indoor
Metal
Enclosure
Indoor
Plastic
4pin Molex Micro-Fit Connector
Yes
4pin Molex Micro-Fit Connector
Yes
4pin Molex Micro-Fit Connector
Yes
Terminal Block Power Connector for Mobile / Vehicular Deployment
No
Terminal Block Power Connector for Mobile / Vehicular Deployment
Yes
Terminal Block Power Connector for Mobile / Vehicular Deployment
No
AC Adapter or PSU
AC Input 100V–240V
DC Output 12V
AC Adapter or PSU
AC Input 100V–240V
DC Output 12V 2A
AC Adapter or PSU
AC Input 100V–240V
DC Output 12V 3A
Input voltage
DC 10–30V
Input voltage
Power Port: DC 12–56V
2x USB-C Port: 20V
Input voltage
DC 10–30V
PoE Input
Yes 20
1x 802.3at PoE port provide a power supply of 25W. If you require 30W of power budget (eg. using dual cellular WAN and USB WAN together), please empower the MAX BR2 Pro via the bundled power adapter (12V3A PSU, ACW-663), or the optional Passive PoE Injector Kit (ACW-111 + ACW-622).
PoE Input
No
PoE Input
No
PoE Output
No
PoE Output
No
PoE Output
No
USB Power Input
No
USB Power Input
Yes (9V)
USB Power Input
No
Nominal Power Consumption
NA
Nominal Power Consumption
10W
Nominal Power Consumption
7W
Maximum Power Consumption
30W
Maximum Power Consumption
18W
Dimensions in inches
8.58 x 7.68 x 1.61 inches
Dimensions in inches
6.3 x 3.8 x 1.3 inches
Dimensions in inches
10.31 x 6.33 x 1.31inch
Dimensions in mm
218 x 195 x 29.5 mm
Dimensions in mm
160 x 97 x 33.5 mm
Dimensions in mm
262 x 161 x 33.5mm
Weight (Pound)
2.42 pounds
Weight (Pound)
1.61 pounds
Weight (Pound)
1.7 pounds
Weight (Gram / Kilogram)
1.1 kg
Weight (Gram / Kilogram)
730 grams
Weight (Gram / Kilogram)
756 grams
Operating Temperature
-40°–149°F
-40°–65°C
Operating Temperature
-40°–149°F
-40°–65°C
Operating Temperature
-40°–113°F
-40°–45°C
Humidity
15%–95% (non-condensing)
Humidity
15%–95% (non-condensing)
Humidity
10%–90% (non-condensing)
Rack-mount
No
Rack-mount
No
Rack-mount
No
Dual Hot Swap Power Supply
No
Dual Hot Swap Power Supply
No
Dual Hot Swap Power Supply
No
Warranty Info
No differences
Warranty
1-Year Limited Warranty
Warranty
1-Year Limited Warranty
Warranty
1-Year Limited Warranty
